Raspberry Pi Zero W
Product Details
Overview
The Raspberry Pi Zero W is the wireless member of the Zero family: half the size of a Model A+, but with 2.4 GHz 802.11n Wi-Fi and Bluetooth 4.1 / BLE built in. At 65 × 30 mm and only a few grams, it slips into projects where a full-size Raspberry Pi simply will not fit.
It keeps everything that made the original Pi Zero popular — a 1 GHz single-core ARM11 processor, 512 MB of RAM, mini-HDMI output, micro-USB OTG and a CSI camera connector — and adds the wireless connectivity that turns it into a genuinely useful little IoT node. Ideal for sensor nodes, wearables, retro-gaming builds, network monitors and any project that needs Linux in a very small space.
Key Features
- Processor — Broadcom BCM2835, single-core ARM11 at 1 GHz
- Memory — 512 MB LPDDR2 SDRAM
- Wireless — 2.4 GHz 802.11n Wi-Fi, Bluetooth 4.1 and Bluetooth Low Energy
- Tiny footprint — 65 × 30 × 5 mm, low enough power draw to run from a battery
- Connections — Mini-HDMI, micro-USB OTG data port, separate micro-USB power input
- Camera — CSI-2 camera connector (requires a Zero-format ribbon cable)
- Expansion — 40-pin GPIO footprint, unpopulated — solder your own header for full HAT compatibility
Specifications
| Brand | Raspberry Pi |
|---|---|
| Model | Raspberry Pi Zero W |
| Processor | Broadcom BCM2835, single-core ARM11 |
| Clock speed | 1 GHz |
| Memory | 512 MB LPDDR2 SDRAM |
| Wireless | 2.4 GHz 802.11n Wi-Fi, Bluetooth 4.1 / BLE |
| Video | Mini-HDMI, composite video via test pads |
| USB | 1 × micro-USB OTG (data), 1 × micro-USB (power only) |
| Camera | CSI-2 connector (Zero-format ribbon cable required) |
| GPIO | 40-pin footprint, header not fitted |
| Storage | microSD card slot (card not included) |
| Power input | 5 V via micro-USB |
| Board size | 65 × 30 × 5 mm |
| Operating system | Raspberry Pi OS and other Linux distributions |
What's in the Box
- 1 × Raspberry Pi Zero W board (motherboard only)
GPIO header, microSD card, power supply, adapters and camera cable are sold separately.
Raspberry Pi Zero W
- Official Raspberry Pi Zero W, just 65 x 30 mm
- 1 GHz ARM11 processor with 512 MB RAM, 2.4 GHz Wi-Fi and Bluetooth 4.1
- Board only - GPIO header, cable and adapters sold separately
